Russian Air-to-Air missiles
GarryB- Posts : 40595
Points : 41097
Join date : 2010-03-30
Location : New Zealand
- Post n°151
Re: Russian Air-to-Air missiles
Actually for the prices of conventional bombs and rockets you would be better to look to companies like Bazalt... http://bazalt.ru/en/
nastle77- Posts : 229
Points : 307
Join date : 2015-07-26
- Post n°152
R-24R and R-24T
I just wanted to confirm the ranges for these missiles
The information I have is only for R-23R and R-23T which were 35 km an 15 km respectively, I'm assuming the R-24 had longer ranges ?
The information I have is only for R-23R and R-23T which were 35 km an 15 km respectively, I'm assuming the R-24 had longer ranges ?
GarryB- Posts : 40595
Points : 41097
Join date : 2010-03-30
Location : New Zealand
- Post n°153
Re: Russian Air-to-Air missiles
Just from memory the 35 and 15km ranges were head on lock on ranges based on the seeker performance.
Obviously a receeding target could be engaged at greater ranges because of better IR view of engines with the IR guided model.
i seem to remember the head on engagement range of the radar homing R-24 as being something like 55km or so.
Obviously a receeding target could be engaged at greater ranges because of better IR view of engines with the IR guided model.
i seem to remember the head on engagement range of the radar homing R-24 as being something like 55km or so.
Austin- Posts : 7617
Points : 8014
Join date : 2010-05-09
Location : India
- Post n°154
Re: Russian Air-to-Air missiles
I was having discussion with colleague in BRF and it seems Russia has not ordered the R-27 yet , most of the picture of Su-27 even in Syria is shown with R-27 and not R-77 , so it true that RuAF has not ordered R-77 ?
Also it seems R-77 has design issues ?
http://forums.bharat-rakshak.com/viewtopic.php?f=3&t=6806&start=3920#p1909818
Also it seems R-77 has design issues ?
http://forums.bharat-rakshak.com/viewtopic.php?f=3&t=6806&start=3920#p1909818
Stealthflanker- Posts : 1459
Points : 1535
Join date : 2009-08-05
Age : 36
Location : Indonesia
- Post n°155
Re: Russian Air-to-Air missiles
Austin wrote:I was having discussion with colleague in BRF and it seems Russia has not ordered the R-27 yet , most of the picture of Su-27 even in Syria is shown with R-27 and not R-77 , so it true that RuAF has not ordered R-77 ?
Yes.
Also it seems R-77 has design issues ?
http://forums.bharat-rakshak.com/viewtopic.php?f=3&t=6806&start=3920#p1909818
I am not sure about that "reliability and engineering problem" Given that our own flanker (Indonesian) Also used R-77 and successfully tested it.
One thing however.. Carlo Kopp stated that the 9B-1348 seeker for R-77 using Texas Instrument Digital signal processor chip (TMS-320) Perhaps that could be the problem.
medo- Posts : 4343
Points : 4423
Join date : 2010-10-25
Location : Slovenia
- Post n°156
Re: Russian Air-to-Air missiles
Austin wrote:I was having discussion with colleague in BRF and it seems Russia has not ordered the R-27 yet , most of the picture of Su-27 even in Syria is shown with R-27 and not R-77 , so it true that RuAF has not ordered R-77 ?
Also it seems R-77 has design issues ?
http://forums.bharat-rakshak.com/viewtopic.php?f=3&t=6806&start=3920#p1909818
Russia have ordered R-77-1 missiles and first missiles will be delivered to RuAF in this year. As you could see on the photo, operational Su-35 regiment already have launch adapters for R-77-1 missiles. Most probably Su-35 and Su-30SM units will be the first equipped with those missiles. I think we will more often see them next year, when RuAF will receive larger number of them.
If you ask specifically for R-77 missiles, than answer is no, RuAF didn't order R-77 missiles, they order R-77-1 missiles.
sepheronx- Posts : 8857
Points : 9117
Join date : 2009-08-06
Age : 35
Location : Canada
- Post n°157
Re: Russian Air-to-Air missiles
medo wrote:Austin wrote:I was having discussion with colleague in BRF and it seems Russia has not ordered the R-27 yet , most of the picture of Su-27 even in Syria is shown with R-27 and not R-77 , so it true that RuAF has not ordered R-77 ?
Also it seems R-77 has design issues ?
http://forums.bharat-rakshak.com/viewtopic.php?f=3&t=6806&start=3920#p1909818
Russia have ordered R-77-1 missiles and first missiles will be delivered to RuAF in this year. As you could see on the photo, operational Su-35 regiment already have launch adapters for R-77-1 missiles. Most probably Su-35 and Su-30SM units will be the first equipped with those missiles. I think we will more often see them next year, when RuAF will receive larger number of them.
If you ask specifically for R-77 missiles, than answer is no, RuAF didn't order R-77 missiles, they order R-77-1 missiles.
What are the differences? R-77-1 uses Russian made components?
jhelb- Posts : 1095
Points : 1196
Join date : 2015-04-04
Location : Previously: Belarus Currently: A Small Island No One Cares About
- Post n°158
Re: Russian Air-to-Air missiles
medo wrote:Russia have ordered R-77-1 missiles and first missiles will be delivered to RuAF in this year.
Seeker upgrade for the Izdeliye 170-1(R-77-1) is not yet over, so it is unlikely to be delivered this year.
medo- Posts : 4343
Points : 4423
Join date : 2010-10-25
Location : Slovenia
- Post n°159
Re: Russian Air-to-Air missiles
http://bmpd.livejournal.com/1448231.html
http://lenta.ru/news/2015/08/26/raketa/
R-77-1 are already in production and Russian MoD ordered them. Missiles are fully Russian without components from Ukraine. They said to have a problem with a seeker for short range AAM, not for R-77-1.
http://lenta.ru/news/2015/08/26/raketa/
R-77-1 are already in production and Russian MoD ordered them. Missiles are fully Russian without components from Ukraine. They said to have a problem with a seeker for short range AAM, not for R-77-1.
Austin- Posts : 7617
Points : 8014
Join date : 2010-05-09
Location : India
- Post n°160
Re: Russian Air-to-Air missiles
Thanks so no R-77 but R-77-1
Did RuAF have R-27AE active radar variant ?
Did RuAF have R-27AE active radar variant ?
medo- Posts : 4343
Points : 4423
Join date : 2010-10-25
Location : Slovenia
- Post n°161
Re: Russian Air-to-Air missiles
Austin wrote:Thanks so no R-77 but R-77-1
Did RuAF have R-27AE active radar variant ?
Difficult to say. Officially not, but externally R-27AE is the same as R-27ER, so they could easily hide them behind R-27ER.
Austin- Posts : 7617
Points : 8014
Join date : 2010-05-09
Location : India
- Post n°162
Re: Russian Air-to-Air missiles
So why were they exporting R-77 when their own force didn't buy one
magnumcromagnon- Posts : 8138
Points : 8273
Join date : 2013-12-05
Location : Pindos ave., Pindosville, Pindosylvania, Pindostan
- Post n°163
Re: Russian Air-to-Air missiles
Austin wrote:So why were they exporting R-77 when their own force didn't buy one
What makes you think the export missile is the same as the domestic missile?
GarryB- Posts : 40595
Points : 41097
Join date : 2010-03-30
Location : New Zealand
- Post n°164
Russian Air-to-Air missiles
Up until recently there haven't been that many Russian Air Force aircraft that could use R-77 that were actually in service in numbers (as opposed to prototypes and sales models trotted out for air shows).
The MiG-29SM and MiG-29SMT and the Su-27SM and Su-30SM, plus Su-34 and Su-35 would be able to carry them but for the vast majority of in service aircraft like the MiG-29 and Su-27P they were not compatible.
The R-27 is not a bad weapon that has a very wide variety of types and is cheap and would be effective enough.
even with the introduction of R-77 and later missiles I suggest the R-27ET will remain in use as there doesn't seem to be a long range IR guided alternative so far...
Note both the R-37 and R-77 have hydraulic rams built into their launch pylons to allow conformal and internal launch positions... the missile is thrown down clear of the aircraft before the missiles rocket motor is started to prevent the airflow around the aircraft fuselage and wings from blowing the missile back up into the aircraft doing damage on launch.
The MiG-29SM and MiG-29SMT and the Su-27SM and Su-30SM, plus Su-34 and Su-35 would be able to carry them but for the vast majority of in service aircraft like the MiG-29 and Su-27P they were not compatible.
The R-27 is not a bad weapon that has a very wide variety of types and is cheap and would be effective enough.
even with the introduction of R-77 and later missiles I suggest the R-27ET will remain in use as there doesn't seem to be a long range IR guided alternative so far...
Note both the R-37 and R-77 have hydraulic rams built into their launch pylons to allow conformal and internal launch positions... the missile is thrown down clear of the aircraft before the missiles rocket motor is started to prevent the airflow around the aircraft fuselage and wings from blowing the missile back up into the aircraft doing damage on launch.
George1- Posts : 18529
Points : 19034
Join date : 2011-12-23
Location : Greece
- Post n°165
Re: Russian Air-to-Air missiles
Aerial Missiles That Protect Russian Bombers in Syria Revealed (Photos)
R-73 missile
R-27ER missile
Su-30SM fighters, which are part of Russia’s anti-ISIL campaign in Syria, are armed with R-73 short-range and R-27R medium-to-long-range air-to-air missiles, representatives of the Russian Air Force told journalists at the Hmeymim airbase in Latakia.
The Russian airstrike group in Syria includes Sukhoi Su-24s, Su-25s and Su-34s, as well as several Su-30SM fighters. The main objective of these fighter jets is to protect Russian bombers, striking ISIL positions in the air, from possible enemy fighters.
For this purpose the Sukhoi fighter jets are armed with R-73 and R-27R (and its modification R-27ER) air-to-air missiles. Each plane can carry 12 of these deadly missiles, but usually Russian fighters carry six of them for greater maneuverability.
The R-73 short-range air-to-air missiles are designed for close-range aerial combat, with a range of no more than 30 kilometers. The R-73 missile is equipped with an infrared-homing (heat-seeking) head that provides extreme precision when hitting targets. Pilots can fire R-73 missiles using a helmet-mounted sight (HMS) system of targeting.
In addition to the short-range missiles, Su-30SM flankers are equipped with R-27R and R-27ER medium-to-long-range missiles. The R-27R and R-27ER missiles can be used between 20 and 27,000 meters altitude and are equipped with an active-radar-homing head that allows the missile to find and track its targets autonomously. Active-radar-homing missiles are extremely accurate and have one of the best kill probabilities among all modern air-to-air missiles.
Russia launched an airstrike campaign aimed at assisting the Damascus-led forces in their fight against extremist groups in Syria, including Islamic State, following a request from the government of Bashar al-Assad.
Read more: http://sputniknews.com/military/20151019/1028776200/air-to-air-missiles-su-30-syria.html#ixzz3p33f8nth
R-73 missile
R-27ER missile
Su-30SM fighters, which are part of Russia’s anti-ISIL campaign in Syria, are armed with R-73 short-range and R-27R medium-to-long-range air-to-air missiles, representatives of the Russian Air Force told journalists at the Hmeymim airbase in Latakia.
The Russian airstrike group in Syria includes Sukhoi Su-24s, Su-25s and Su-34s, as well as several Su-30SM fighters. The main objective of these fighter jets is to protect Russian bombers, striking ISIL positions in the air, from possible enemy fighters.
For this purpose the Sukhoi fighter jets are armed with R-73 and R-27R (and its modification R-27ER) air-to-air missiles. Each plane can carry 12 of these deadly missiles, but usually Russian fighters carry six of them for greater maneuverability.
The R-73 short-range air-to-air missiles are designed for close-range aerial combat, with a range of no more than 30 kilometers. The R-73 missile is equipped with an infrared-homing (heat-seeking) head that provides extreme precision when hitting targets. Pilots can fire R-73 missiles using a helmet-mounted sight (HMS) system of targeting.
In addition to the short-range missiles, Su-30SM flankers are equipped with R-27R and R-27ER medium-to-long-range missiles. The R-27R and R-27ER missiles can be used between 20 and 27,000 meters altitude and are equipped with an active-radar-homing head that allows the missile to find and track its targets autonomously. Active-radar-homing missiles are extremely accurate and have one of the best kill probabilities among all modern air-to-air missiles.
Russia launched an airstrike campaign aimed at assisting the Damascus-led forces in their fight against extremist groups in Syria, including Islamic State, following a request from the government of Bashar al-Assad.
Read more: http://sputniknews.com/military/20151019/1028776200/air-to-air-missiles-su-30-syria.html#ixzz3p33f8nth
nastle77- Posts : 229
Points : 307
Join date : 2015-07-26
- Post n°166
Re: Russian Air-to-Air missiles
George1 wrote:Aerial Missiles That Protect Russian Bombers in Syria Revealed (Photos)
R-73 missile
R-27ER missile
Su-30SM fighters, which are part of Russia’s anti-ISIL campaign in Syria, are armed with R-73 short-range and R-27R medium-to-long-range air-to-air missiles, representatives of the Russian Air Force told journalists at the Hmeymim airbase in Latakia.
The Russian airstrike group in Syria includes Sukhoi Su-24s, Su-25s and Su-34s, as well as several Su-30SM fighters. The main objective of these fighter jets is to protect Russian bombers, striking ISIL positions in the air, from possible enemy fighters.
For this purpose the Sukhoi fighter jets are armed with R-73 and R-27R (and its modification R-27ER) air-to-air missiles. Each plane can carry 12 of these deadly missiles, but usually Russian fighters carry six of them for greater maneuverability.
The R-73 short-range air-to-air missiles are designed for close-range aerial combat, with a range of no more than 30 kilometers. The R-73 missile is equipped with an infrared-homing (heat-seeking) head that provides extreme precision when hitting targets. Pilots can fire R-73 missiles using a helmet-mounted sight (HMS) system of targeting.
In addition to the short-range missiles, Su-30SM flankers are equipped with R-27R and R-27ER medium-to-long-range missiles. The R-27R and R-27ER missiles can be used between 20 and 27,000 meters altitude and are equipped with an active-radar-homing head that allows the missile to find and track its targets autonomously. Active-radar-homing missiles are extremely accurate and have one of the best kill probabilities among all modern air-to-air missiles.
Russia launched an airstrike campaign aimed at assisting the Damascus-led forces in their fight against extremist groups in Syria, including Islamic State, following a request from the government of Bashar al-Assad.
Read more: http://sputniknews.com/military/20151019/1028776200/air-to-air-missiles-su-30-syria.html#ixzz3p33f8nth
when did the full scale production of R-73 start and approx. how many were made by 1990 ?
Thanks
nastle77- Posts : 229
Points : 307
Join date : 2015-07-26
- Post n°167
Re: Russian Air-to-Air missiles
WHat is the max engagement range of R-60M front and rear aspect ?
GarryB- Posts : 40595
Points : 41097
Join date : 2010-03-30
Location : New Zealand
- Post n°168
Re: Russian Air-to-Air missiles
First of all that picture of the R-73 is a dummy version.... the white missile with black stripes indicates that.
And by definition the R-27R and R-27ER are SARH missiles.... that is what the second R means in both designations... ie R= in service air to air missile, -27 means model 27, while the last R means SARH, while the E is the extended range model with larger rocket motor (note the image of the R-27 shows the R-27ER.
The IR guided version of R-27 and R-27E has the same IR seeker as the R-73, and any weapon can be aimed using the helmet mounted sight...
From memory full scale production started about the mid 1980s and they were made in very large numbers.
AFAIK the max head on range is about 10km and the tail launch range is about 4km for subsonic targets.
And by definition the R-27R and R-27ER are SARH missiles.... that is what the second R means in both designations... ie R= in service air to air missile, -27 means model 27, while the last R means SARH, while the E is the extended range model with larger rocket motor (note the image of the R-27 shows the R-27ER.
The IR guided version of R-27 and R-27E has the same IR seeker as the R-73, and any weapon can be aimed using the helmet mounted sight...
when did the full scale production of R-73 start and approx. how many were made by 1990 ?
Thanks
From memory full scale production started about the mid 1980s and they were made in very large numbers.
WHat is the max engagement range of R-60M front and rear aspect ?
AFAIK the max head on range is about 10km and the tail launch range is about 4km for subsonic targets.
mack8- Posts : 1039
Points : 1093
Join date : 2013-08-03
- Post n°169
Re: Russian Air-to-Air missiles
According to this interview RVV-SD has been in production for 3 years already. If i'm not mistaken , we saw the AKU-170 adapter on Su-35S, Su-30SM and now MiG-31BM, so the R-77-1 must definitely be in service, but probably still secret atm.
http://alexeyvvo.livejournal.com/152522.html
http://alexeyvvo.livejournal.com/152522.html
medo- Posts : 4343
Points : 4423
Join date : 2010-10-25
Location : Slovenia
- Post n°170
Re: Russian Air-to-Air missiles
mack8 wrote:According to this interview RVV-SD has been in production for 3 years already. If i'm not mistaken , we saw the AKU-170 adapter on Su-35S, Su-30SM and now MiG-31BM, so the R-77-1 must definitely be in service, but probably still secret atm.
http://alexeyvvo.livejournal.com/152522.html
Most probably for now in storages for war use, but for everyday patrols they still use R-27 missiles. But it would be nice to see training R-77-1 rounds on the planes. I wonder if they will bring some R-77-1 missiles for Su-30SM and Su-34 in Syria.
artjomh- Posts : 150
Points : 184
Join date : 2015-07-17
- Post n°171
Re: Russian Air-to-Air missiles
mack8 wrote:According to this interview RVV-SD has been in production for 3 years already. If i'm not mistaken , we saw the AKU-170 adapter on Su-35S, Su-30SM and now MiG-31BM, so the R-77-1 must definitely be in service, but probably still secret atm.
http://alexeyvvo.livejournal.com/152522.html
RVV-SD is an export missile.
Berkut- Posts : 190
Points : 215
Join date : 2015-05-06
- Post n°172
Re: Russian Air-to-Air missiles
artjomh wrote:mack8 wrote:According to this interview RVV-SD has been in production for 3 years already. If i'm not mistaken , we saw the AKU-170 adapter on Su-35S, Su-30SM and now MiG-31BM, so the R-77-1 must definitely be in service, but probably still secret atm.
http://alexeyvvo.livejournal.com/152522.html
RVV-SD is an export missile.
R-77-1 under RVV-SD designation is, R-77-1, isnt.
artjomh- Posts : 150
Points : 184
Join date : 2015-07-17
- Post n°173
Re: Russian Air-to-Air missiles
Berkut wrote:artjomh wrote:mack8 wrote:According to this interview RVV-SD has been in production for 3 years already. If i'm not mistaken , we saw the AKU-170 adapter on Su-35S, Su-30SM and now MiG-31BM, so the R-77-1 must definitely be in service, but probably still secret atm.
http://alexeyvvo.livejournal.com/152522.html
RVV-SD is an export missile.
R-77-1 under RVV-SD designation is, R-77-1, isnt.
Well, I am just referring to the fact that RVV-SD is in production doesn't mean this is for the Russian Military, or that this is proof that RuAF has operational R-77-1 stocks.
Berkut- Posts : 190
Points : 215
Join date : 2015-05-06
- Post n°174
Re: Russian Air-to-Air missiles
If a MiG-31BM pilot told me that he has personally seen R-77-1 and sent me a pic of AKU-170's on MiG-31BM; what does that tell you?
mack8- Posts : 1039
Points : 1093
Join date : 2013-08-03
- Post n°175
Re: Russian Air-to-Air missiles
Hi Berkut, have you heard anything about the Su-30SM units receiving R-77-1s? I know the pic of bort 56 with AKU-170s, but don't recall seeing other SM borts with those adapters. Thanks.
