Analysis of guiding unit of 9M544 missile.
Per request, we are doing a brief review of imported components in the SNS block from the 9M544 projectile.

What do we see?
- 2 chips in TSOP66 package. On such microcircuits, as a rule, memory modules are assembled. Russia DOES NOT produce chips in such packages.
- Tantalum SMD capacitors. On aliexpress in excess.
- DB15 connector. It is NOT produced in Russia.
- SMA connector. It is NOT produced in Russia.
- 3 ICs in LQFP64 package (low profile ICs).
Here our patriotic subscribers, vehemently preaching the protective look "not caught - not a thief!", are waiting for victory! In Russia, controllers are produced in such a package, for example, K1986BE92QI from Milandra. True, the win ends here, because microcircuits in this package are declared by the manufacturer as acceptance of "OTK 1", i.e. for civil and household appliances (consumer goods). For a military grade, it is permissible to use ECB with acceptance of VP (OTK 5 and higher).

In general, there is not a single microcircuit on the board that could fit into the military category (OTC 5 VP +). All microcircuits of the "commercial" class (OTK 1-3), i.e. for use in civil, household appliances. (consumer goods).
